Automatic 5-Layer 1000L Extrusion Blow Molding Machine for Water Tanks
| 원래 장소 | 중국 |
|---|---|
| 브랜드 이름 | HUAYU |
| 인증 | ISO9001 CE |
| 모델 번호 | HYBM-200-1000L,5레이어 |
| 최소 주문 수량 | 1세트 |
| 가격 | 260000 USD |
| 포장 세부 사항 | 컨테이너 운송을 위해 많은 부품으로 분해됩니다 |
| 배달 시간 | 4개월 |
| 지불 조건 | T/T,L/C |
| 공급 능력 | 1 세트 120 일 |
무료 샘플과 쿠폰을 받으려면 연락하세요.
WhatsApp:0086 18588475571
웨이 채팅: 0086 18588475571
스카이프: sales10@aixton.com
걱정이 있으시면 24시간 온라인 서비스를 제공합니다.
x제품 상세 정보
| 전압 | 미결정 | 총 전력 | 402kw |
|---|---|---|---|
| 평균 전력 | 220kW | 기계 치수(L*W*H) | 8*9*6.5 |
| 생산력 | 16-25개/시간 | 나사 직경 | 80/80/80/80/80mm |
| 나사 L/D 비율 | 28 ： 1 | 축적자 능력 | 35kg |
| 다이 경 | 제품에 따르면 | Max. 최대. Mould size 금형 크기 | 1200*1500mm(폭*높이) |
| 최대 공기압 | 0.8Mpa | 공기 소비량 | 1.5M3/min |
| 강조하다 | 6-Layer Extrusion Blow Molding Machine,1000L Blow Moulding Machine,Automatic Water Tank Blow Moulding Machine |
||
제품 설명
Automatic 5-Layer Extrusion Blow Molding Machine (1000L)
Our 1000L 5-Layer Blow Molding Machine represents the pinnacle of engineering excellence, designed for manufacturers who demand superior quality containers and optimal production performance.
Key Features
- Multi-Layer Construction: 5-layer structure enables strategic material placement for lighter, stronger, and more cost-effective finished products with enhanced performance characteristics.
- High-Capacity Production: Engineered for maximum yield with robust components designed for consistent, high-quality output in demanding 24/7 production environments.
- Advanced Control System: Intuitive operation with cutting-edge control technology providing precise oversight and customization for optimal production orchestration.
Hydraulic System Specifications
| Main Oil Tank Capacity | 890L |
| Main Oil Pump | Gear Pump 125CC |
| Main Oil Pump Motor | 37kW |
| Servo Oil Tank Capacity | 200L |
| Servo Oil Pump Model | Plunger Pump 22 |
| Servo Oil Pump Motor | 7.5kW |
Electronic System Specifications
| Main Operation Panel | Touch Screen 9" |
| Control System | PLC |
| Thickness Control Points | 200 Points |
| Temperature Control | PLC Module |
This machine features a servo motor system for reduced energy consumption, high efficiency, and low noise operation, providing a significant competitive advantage for your manufacturing operations.
